Providing Disaster Recovery to CloudBees-Jenkins in AKS with Astra Control Service

August 2, 2022

Topics: Azure NetApp FilesAstra 25 minute read

Introduction

NetApp® Astra™ Control is a solution that makes it easier to manage, protect, and move data-rich Kubernetes workloads within and across public clouds and on-premises. Astra Control provides persistent container storage that leverages NetApp’s proven and expansive storage portfolio in the public cloud and on-premises, supporting Azure managed disks as storage backend options as well.

Astra Control also offers a rich set of application-aware data management functionality (like snapshot and restore, backup and restore, activity logs, and active cloning) for local data protection, disaster recovery, data audit, and mobility use cases for your modern apps. Astra Control provides complete protection of stateful Kubernetes applications by saving both data and metadata, like deployments, config maps, services, secrets, that constitute an application in Kubernetes. Astra Control can be managed via its user interface, accessed by any web browser, or via its powerful REST API.

Astra Control has two variants:

  1. Astra Control Service (ACS) – A fully managed application-aware data management service that supports Azure Kubernetes Service (AKS), Azure Disk Storage, and Azure NetApp Files (ANF).
  2. Astra Control Center (ACC) – application-aware data management for on-premises Kubernetes clusters, delivered as a customer-managed Kubernetes application from NetApp.

To demonstrate Astra Control’s backup and recovery capabilities in AKS, we use CloudBees CI, a solution for providing Continuous Integration based on Jenkins instances. CloudBees Software Delivery Automation CI is a fully-featured, cloud native capability that can be hosted on-premises or in the public cloud and is used to deliver CI at scale. It provides a shared, centrally managed, self-service experience for all your development teams running Jenkins. CloudBees CI on modern cloud platforms is designed to run on Kubernetes. In this case, we are deploying CloudBees CI on Azure Kubernetes Service (AKS).

The Kubernetes resources created by CloudBees CI are the following:

  • 1 Load Balancer with public IP address that is normally pointing to main domain name (resolvable by DNS), e.g., my-cloudbees.com
  • 1 statefulset + 1 PVC + 1 service + 1 ingress controller for CloudBees Jenkins Operations Console (CJOC): my-cloudbees.com/cjoc
  • 1 statefulset + 1 PVC + 1 service + 1 ingress controller for each controller aka Jenkins instance that is created inside CloudBees: my-cloudbees.com/my-cool-cicd-1
  • All ingress controllers belong to the same public IP address: the one of the Load Balancer for the main domain name.
  • With new Kubernetes versions the ingress class used by CloudBees is nginx type instead of using default ingress controllers
  • The PVCs are backed by Azure NetApp Files, dynamically provisioned using Astra Trident – NetApp’s CSI spec compliant K8s storage orchestrator.

Thanks to the latest improvements in Astra Control Service, we can now protect with snapshots and backups, not only the data stored by Jenkins in the PVC, but also ALL the above Kubernetes resources.

Scenario

In the following scenario, we will demonstrate how Astra Control Service can protect all resources in a CloudBees CI deployment on an AKS cluster in a European region and recover the full application in a different AKS cluster in a US region.

Deploying CloudBees CI - Jenkins

First, we create two AKS clusters, our main "production" cluster called cloudbees-main in West Europe and another cluster for disaster-recovery called cloudbees-dr in West US regions.

blog1-Jul-27-2022-05-19-07-82-AM
Then, we create Azure NetApp Files (ANF) accounts and capacity pools in both regions. We also have to connect via a specific vnet the AKS cluster with ANF account in the same region. We can see below two different ANF accounts with the same names as the AKS clusters, and using the same Resource Groups, in the same regions.

blog2-Jul-27-2022-05-19-53-24-AM
After that, we can log on to our Astra Control Service (ACS) account and "Add" both clusters to be registered and protected by ACS.

In our ACS console we don't have any managed Kubernetes clusters yet, we must click on the button add in the Clusters section:

blog3-Jul-27-2022-05-20-05-13-AM
Then, we provide the right credentials at the beginning of the wizard, selecting Microsoft Azure, to let ACS scan with that credential which AKS clusters are available to register.

blog4-Jul-27-2022-05-20-17-06-AM
Now, we select first the cluster cloudbees-main, to be registered by ACS. ACS checks that there is Azure NetApp Files available to be used by AKS through CSI provisioner Astra Trident, marking the OK green sign in the Eligible column:

blog5-4
ACS detects automatically ANF capacity pools reachable by the AKS cluster and will install and automatically configure Astra Trident in the namespace trident in the AKS cluster, for enabling dynamic provisioning of ANF volumes, creating a new Storage Class for ANF.

Note: ACS can also protect applications on AKS clusters using Azure Disk for persistent storage

In the next step of the wizard, we will select the CSI storage class we want to set as Default Storage Class for our AKS cluster. In this case, we choose the ANF storage class netapp-anf-perf-premium as the default.

blog6-4
In the last step, a summary of our actions appears to get confirmation.

blog7-4
After clicking "Add", ACS installs and configures Astra Trident in the AKS cluster.

We can repeat the same steps with our AKS cluster for Disaster Recovery cloudbees-dr.

Now, we have in our ACS console both AKS clusters managed by ACS, providing information about the health, location, and version of the clusters, in this case we are using Kubernetes v1.21.9:

blog8-4
Now, we are ready to deploy CloudBees CI in our cloudbees-main AKS cluster, using ANF as the default persistent storage.

Following the instructions on how to deploy CloudBees CI on modern cloud platforms, we need to use a helm chart. We add the repo, update it, create a dedicated namespace called cloudbees-core for our deployment, and deploy CloudBees using helm with nginx as ingressclass:

$ kubectl cluster-info
Kubernetes control plane is running at https://cloudbees--westeu-cloudbees-b2896f-19fbb235.hcp.westeurope.azmk8s.io:443
CoreDNS is running at https://cloudbees--westeu-cloudbees-b2896f-19fbb235.hcp.westeurope.azmk8s.io:443/api/v1/namespaces/k...
Metrics-server is running at https://cloudbees--westeu-cloudbees-b2896f-19fbb235.hcp.westeurope.azmk8s.io:443/api/v1/namespaces/k...

To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

$ kubectl get nodes
NAME                                STATUS   ROLES   AGE   VERSION
aks-nodepool1-17876121-vmss000000   Ready    agent   18h   v1.21.9
aks-nodepool1-17876121-vmss000001   Ready    agent   18h   v1.21.9
aks-nodepool1-17876121-vmss000002   Ready    agent   18h   v1.21.9

$ kubectl get namespaces
NAME              STATUS   AGE
default           Active   18h
kube-node-lease   Active   18h
kube-public       Active   18h
kube-system       Active   18h
trident           Active   15h

$ helm repo add cloudbees https://public-charts.artifacts.cloudbees.com/repository/public/
"cloudbees" has been added to your repositories

$ helm repo update
Hang tight while we grab the latest from your chart repositories...
...Successfully got an update from the "cloudbees" chart repository
...Successfully got an update from the "bitnami" chart repository
...Successfully got an update from the "azure-marketplace" chart repository
Update Complete. Happy Helming!

$ kubectl create namespace cloudbees-core
namespace/cloudbees-core created

$ helm install cloudbees-core \
             cloudbees/cloudbees-core \
             --namespace cloudbees-core \
             --set ingress-nginx.Enabled=true
NAME: cloudbees-core
LAST DEPLOYED: Thu Jun 16 13:08:42 2022
NAMESPACE: cloudbees-core
STATUS: deployed
REVISION: 1
TEST SUITE: None
NOTES:
1. Once Operations Center is up and running, get your initial admin user password by running:
    kubectl rollout status sts cjoc --namespace cloudbees-core
    kubectl exec cjoc-0 --namespace cloudbees-core -- cat /var/jenkins_home/secrets/initialAdminPassword
2. Get the OperationsCenter URL to visit by running these commands in the same shell:
    If you have an ingress controller, you can access Operations Center through its external IP or hostname.

    Otherwise you can use the following method:
    export POD_NAME=$(kubectl get pods --namespace cloudbees-core -l "app.kubernetes.io/instance="cloudbees-core",app.kubernetes.io/component=cjoc" -o jsonpath="{.items[0].metadata.name}")
    echo http://127.0.0.1:80
    kubectl port-forward $POD_NAME 80:80

 3. Login with the password from step 1.

For more information on running CloudBees Core on Kubernetes, visit:
https://go.cloudbees.com/docs/cloudbees-core/cloud-admin-guide/



After a few minutes, we can check that all the resources are deployed and get the admin temporary password for configuring CloudBees CI:

$ kubectl -n cloudbees-core get pvc,all,ing
NAME                                        STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS              AGE
persistentvolumeclaim/jenkins-home-cjoc-0   Bound    pvc-8d52d00a-9760-4f58-838a-2a1b889be99e   100Gi      RWO            netapp-anf-perf-premium   63m

NAME                                                          READY   STATUS    RESTARTS   AGE
pod/cjoc-0                                                    1/1     Running   0          63m
pod/cloudbees-core-ingress-nginx-controller-d4784546c-lphd5   1/1     Running   0          63m

NAME                                                        TYPE           CLUSTER-IP     EXTERNAL-IP      PORT(S)                      AGE
service/cjoc                                                ClusterIP      10.0.195.237   <none>           80/TCP,50000/TCP             63m
service/cloudbees-core-ingress-nginx-controller             LoadBalancer   10.0.124.250   20.126.199.140   80:31865/TCP,443:30049/TCP   63m
service/cloudbees-core-ingress-nginx-controller-admission   ClusterIP      10.0.251.134   <none>           443/TCP                      63m

NAME                                                      READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/cloudbees-core-ingress-nginx-controller   1/1     1            1           63m

NAME                                                                DESIRED   CURRENT   READY   AGE
replicaset.apps/cloudbees-core-ingress-nginx-controller-d4784546c   1         1         1       63m

NAME                    READY   AGE
statefulset.apps/cjoc   1/1     63m

NAME                             CLASS   HOSTS   ADDRESS          PORTS   AGE
ingress.networking.k8s.io/cjoc   nginx   *       20.126.199.140   80      63m

$ kubectl rollout status sts cjoc --namespace cloudbees-core
statefulset rolling update complete 1 pods at revision cjoc-c8b96dfdc...

$ kubectl exec cjoc-0 --namespace cloudbees-core -- cat /var/jenkins_home/secrets/initialAdminPassword
73f27870bb81419081e04ad009819fa7

We can also check that a new cluster scoped resource, ingress class of type NGINX has been created:

$ kubectl get ingressclass -o yaml
apiVersion: v1
items:
- apiVersion: networking.k8s.io/v1
  kind: IngressClass
  metadata:
    annotations:
      meta.helm.sh/release-name: cloudbees-core
      meta.helm.sh/release-namespace: cloudbees-core
    creationTimestamp: "2022-06-16T11:08:48Z"
    generation: 1
    labels:
      app.kubernetes.io/component: controller
      app.kubernetes.io/instance: cloudbees-core
      app.kubernetes.io/managed-by: Helm
      app.kubernetes.io/name: ingress-nginx
      app.kubernetes.io/version: 1.1.0
      helm.sh/chart: ingress-nginx-4.0.13
    name: nginx
    resourceVersion: "212469"
    uid: ddaf66b2-339e-48f8-8394-3bb19dfe5688
  spec:
    controller: k8s.io/ingress-nginx
kind: List
metadata:
  resourceVersion: ""
  selfLink: ""

For the sake of simulating a full Disaster Recovery, we are going to use the public IP address provided by the Load Balancer as if it was resolvable by an external DNS server but using our own /etc/hosts. We'll call the domain: my-cloudbees.com, and use it for everything related to our CloudBees CI deployment:

$ cat /etc/hosts
##
# Host Database
#
# localhost is used to configure the loopback interface
# when the system is booting.  Do not change this entry.
##
127.0.0.1    localhost
255.255.255.255     broadcasthost
::1             localhost
20.126.199.140      my-cloudbees.com

Now, we can navigate in our local browser to my-cloudbees.com and complete the configuration of the CloudBees CI.

blog9-4

In the next step, we can request a trial license to activate the product, filling in a form with our corporate details.

blog10-4

After that, CloudBees CI will propose to install a series of recommended/suggested plug-ins for general management.

blog11-3

Then, we create our first Admin user luis to avoid using the Admin temporary password again.

blog12-3

Then, CloudBees gets configured using the domain name we specified when accessing with the browser: mycloudbees.com/cjoc

blog13-3

This is important because when recovering from a disaster we need to change the IP address of this domain name, as all the components are sub-domains using same public IP address. We change the corporate DNS (in our case, the local /etc/hosts) to point to the new IP address for the recovered CloudBees CI service, that will be the public IP address of the new Load Balancer in our cloudbees-dr AKS cluster. Using domain names facilitate the recovery, as all Jenkins instances will be sub-domains of the same main domain name, and therefore resolvable after Disaster Recovery.

blog14-3

After that, we'll land in the CJOC (CloudBees Jenkins Operations Center) dashboard:

blog15-2
Configuring CloudBees-CI-Jenkins

To demonstrate how Astra Control Service protects and provides DR for a complex Kubernetes deployment that is massively scalable like CloudBees CI, we'll configure our CloudBees CI deployment to have a more realistic environment.

CloudBees allows us to centrally manage and control Jenkins instances to provide CI/CD pipelines for the development of new applications. Every Jenkins instance is called a Controller. As explained before, each Controller creates in the cloudbees-core namespace (each controller can be created in a different namespace), the following Kubernetes resources: 1 Stateful Set + 1 PVC + 1 service + 1 ingress controller for each Controller (Jenkins instance) that is created inside CloudBees, and it creates an ingress controller as a new path in the main domain name, for example: my-cloudbees.com/my-cool-cicd-1

Dozens of controllers can be created in a single CloudBees CI deployment, to dedicate Jenkins instances for different development teams or applications.

We are going to create 4 new controllers, Jenkins instances, with some pipeline jobs inside the controllers. These are example pipelines, but for the purpose of simulating the usage of persistent storage by Jenkins instances, one of them will have a special pipeline that artificially stores a big file every time it is built.

This is the aspect of the pipeline code for artificially using more storage in the PV, called make-pv-fat:

pipeline {
    agent {
    kubernetes {
      label 'mypodtemplate-v2'
      defaultContainer 'jnlp'
      yaml """
apiVersion: v1
kind: Pod
metadata:
  labels:
    some-label: some-label-value
spec:
  containers:
  - name: ubuntu
    image: ubuntu
    command:
    - cat
    tty: true
"""
    }
  }
stages {
        stage('Inflate') {
            steps {
                sh 'date'
                sh 'dd if=/dev/urandom of=./$(date +%Y%m%d-%H%M).tmp bs=1M count=10000'

            }
        }
        stage('Archive') {
            steps {
                archiveArtifacts artifacts: '*.tmp',
                   allowEmptyArchive: true,
                   fingerprint: true,
                   onlyIfSuccessful: true
            }
        }
    }
}

As we can see, the pipeline just creates a 10 GB random generated file with dd and stores it in the archive of the Jenkins instance.

We won't go over the details and screenshots about how to configure CloudBees for creating all these controllers and pipelines, but we'll show some pieces of the final configuration in the CloudBees console. More details in the official documentation: https://docs.cloudbees.com/docs/cloudbees-ci/latest/cloud-setup-guide/cloud-setup-guide-intro .

The four controllers, Jenkins instances, up and running:

blog16-2
The pipeline job mentioned earlier called make-pv-fat in the first Controller my-cool-cicd1,

blog17-2
with 2 builds already executed:

It's important to remark again that the pipeline and controller, as marked in red, are available at http://my-cloudbees.com/my-cool-cicd1 that being the subdomain for that Jenkins instance, CloudBees controller.

After this configuration of CloudBees CI, the number of Kubernetes resources in our cloudbees-core namespace has grown considerably, making it more complex to protect as an entire application in Kubernetes with a lot of dependencies between them:

$ kubectl -n cloudbees-core get pvc,all,ing
NAME                                                STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS              AGE
persistentvolumeclaim/jenkins-home-cjoc-0             Bound    pvc-8d52d00a-9760-4f58-838a-2a1b889be99e  100Gi      RWO         netapp-anf-perf-premium   5h16m 5
persistentvolumeclaim/jenkins-home-my-cool-cicd1-0   Bound    pvc-2076e858-4b91-4ee7-9680-58bf3290029e   150Gi      RWO            netapp-anf-perf-premium   143m 7
persistentvolumeclaim/jenkins-home-my-cool-cicd2-0   Bound    pvc-452e271b-62b3-44c3-80e0-d54818754454   100Gi      RWO            netapp-anf-perf-premium   135m 7
persistentvolumeclaim/jenkins-home-my-cool-cicd3-0   Bound    pvc-dec3a2be-c815-4353-b8c2-74f49457e80f   125Gi      RWO            netapp-anf-perf-premium   114m 7
persistentvolumeclaim/jenkins-home-my-cool-cicd4-0   Bound    pvc-37fd5e5d-1477-4379-ab35-a8b4adf36d5b   175Gi       RWO            netapp-anf-perf-premium   103m 7

NAME                                                           READY   STATUS    RESTARTS   AGE
pod/cjoc-0                                                    1/1      Running   0          5h16m 5
pod/cloudbees-core-ingress-nginx-controller-d4784546c-lphd5   1/1      Running   0          5h16m 2
pod/my-cool-cicd1-0                                           1/1     Running   0          143m 7
pod/my-cool-cicd2-0                                           1/1     Running   0        135m 7
pod/my-cool-cicd3-0                                          1/1     Running   0        114m 7
pod/my-cool-cicd4-0                                           1/1     Running   0        103m 7

NAME                                                        TYPE           CLUSTER-IP     EXTERNAL-IP      PORT(S)                      AGE
service/cjoc                                                 ClusterIP        10.0.195.237   <none>            80/TCP,50000/TCP              5h16m 7
service/cloudbees-core-ingress-nginx-controller             LoadBalancer 10.0.124.250   20.126.199.140    80:31865/TCP,443:30049/TCP   5h16m 1
service/cloudbees-core-ingress-nginx-controller-admission  ClusterIP      10.0.251.134   <none>           443/TCP                      5h16m
service/my-cool-cicd1                                        ClusterIP        10.0.243.43    <none>           80/TCP,50001/TCP             143m 6
service/my-cool-cicd2                                       ClusterIP        10.0.34.177    <none>           80/TCP,50002/TCP             135m 6
service/my-cool-cicd3                                       ClusterIP        10.0.13.172    <none>           80/TCP,50003/TCP             114m 6
service/my-cool-cicd4                                       ClusterIP        10.0.148.35    <none>           80/TCP,50004/TCP              103m 6

NAME                                                      READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/cloudbees-core-ingress-nginx-controller   1/1     1            1          5h16m 2

NAME                                                                 DESIRED   CURRENT   READY   AGE
replicaset.apps/cloudbees-core-ingress-nginx-controller-d4784546c   1         1          1       5h16m 2

NAME                             READY   AGE
statefulset.apps/cjoc            1/1     5h16m   5
statefulset.apps/my-cool-cicd1   1/1     143m    7
statefulset.apps/my-cool-cicd2   1/1     135m    7
statefulset.apps/my-cool-cicd3   1/1     114m    7
statefulset.apps/my-cool-cicd4   1/1      103m    7

NAME                                     CLASS   HOSTS   ADDRESS          PORTS   AGE
ingress.networking.k8s.io/cjoc            nginx   *       20.126.199.140   80       5h16m 3
ingress.networking.k8s.io/my-cool-cicd1   nginx   *       20.126.199.140   80     143m 4
ingress.networking.k8s.io/my-cool-cicd2   nginx   *       20.126.199.140   80     135m 4
ingress.networking.k8s.io/my-cool-cicd3   nginx   *       20.126.199.140   80     114m 4
ingress.networking.k8s.io/my-cool-cicd4   nginx   *       20.126.199.140   80     103m 4

We can see there the following

1

Load Balancer service and its public IP address as the main entry point for the outside world, sending traffic to (2)

2

cloudbees-core-ingress-nginx-controller pod, replicaset and deployment, that is responsible to distribute traffic depending on the path to the following nginx class ingress-controllers

3

ingress controller for the CJOC Operations Center, created by default with the deployment of CloudBees CI

4

ingress controllers for each Controller, Jenkins instance, that has been created

5

service attending the traffic from (3) ingress controller for the CJOC, statefulset, PVC and pod for CJOC.

6

services attending the traffic from (4) ingress controllers for each Controller, Jenkins instance, sending traffic to:

7

pods, statefulsets and PVCs for each Controller, with each Jenkins instance.

Protecting CloudBees-CI-Jenkins with Astra Control Service

Switching to the ACS UI, we can see that the CloudBees CI application and cloudbees-core namespace have been discovered by ACS in the "Discovered" tab of Applications section.

blog19
and we can Manage the namespace.

blog20
Now, that is visible in the "Managed" tab, we can see the Warning side explaining that our namespace is "Unprotected".

Before we start protecting the application, let's highlight what Kubernetes Resources are visible in the UI that we are going to protect:

blog21blog22
As we can see, there are 58 Kubernetes Resources, that are going to be protected by Astra. In addition to the Deployments, StatefulSetsServicesReplicaSets, Pods, PVCs, and Ingress controllers explained earlier, we have the ClusterRole, ClusterRoleBindingRoleRoleBinding, ConfigMap, SecretServiceAccount, and ValidatingWebhookConfiguration objects inside the cloudbees-core namespace.

In the "Data protection" tab, we can execute an on-demand snapshot, in the "Snapshots" category button:

blog23
There is a wizard, asking for a name for the snapshot:

blog24
And a summary window to confirm the selection.

blog25
After a few seconds, the snapshot is taken and available. These are CSI compliant snapshots for the PVC part, but all the Kubernetes resources are stored safely as well.

blog26
Snapshots are local to the AKS cluster. If the AKS cluster is destroyed or the namespace is accidentally deleted, snapshots of PVCs are lost. For providing Disaster Recovery, we need backups. Backups are stored externally in Object Storage which can be configured with cross-region redundancy to provide more protection as explained here: https://docs.netapp.com/us-en/astra-control-service/release-notes/known-issues.html#azure-backup-buc...

In the "Data Protection" tab, we can execute an on-demand backup, in the "Backups" category button:

blog27
There is another wizard to guide us through the backup creation. We need to provide a name for the backup, and also select the object storage bucket for the destination of the backup (ACS uses object storage buckets for storing backups, which can be specified by the user or configured automatically by the service). We also need to decide if we want to use an existing snapshot or create a new snapshot while taking a backup.

blog28
Then a summary window appears for confirmation:

blog29
When the backup is initiated, a progress bar appears in the Application Status. We can also see in the "Storage" tab the information about used space for the PVCs coming from ANF storage class.

blog30
Where the largest used size is coming from the PVC used by the Jenkins instance with the pipeline make-pv-fat (20 GB).

With ACS, we can configure a protection policy that takes snapshots and backups periodically (hourly, daily, weekly and monthly) to match RPO/RTO goals for the application.

In the Activity section of the ACS console, we can also track all important activities as snapshots and backups created, and time consumed in those activities:

blog32

Simulating disaster and recovering the application to another cluster

In the next step, we want to test the recovery of the CloudBees CI platform after a simulated disaster.

We'll destroy the cloudbees-main AKS cluster to simulate that disaster and recover from the backup into the cloudbees-dr AKS cluster.

The only resource that is not protected by ACS today is the cluster scope resource ingress class, that is deployed by CloudBees CI as part of the helm chart deployment.

Prior to starting the recovery of cloudbees-core namespace in the cloudbees-dr cluster, we need to create that ingress class. For creating the ingress class, we can export to a yaml file the definition of ingress class in cloudbees-main cluster, "clean" the yaml of uids and state related parameters, and create the yaml in cloudbees-dr cluster:

$ kubectl cluster-info
Kubernetes control plane is running at https://cloudbees--westus-cloudbees-b2896f-6566be8e.hcp.westus.azmk8s.io:443
CoreDNS is running at https://cloudbees--westus-cloudbees-b2896f-6566be8e.hcp.westus.azmk8s.io:443/api/v1/namespaces/kube-...
Metrics-server is running at https://cloudbees--westus-cloudbees-b2896f-6566be8e.hcp.westus.azmk8s.io:443/api/v1/namespaces/kube-...

To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

$ kubectl get nodes
NAME                                STATUS   ROLES   AGE   VERSION
aks-nodepool1-11120100-vmss000000   Ready    agent   26h   v1.21.9
aks-nodepool1-11120100-vmss000001   Ready    agent   26h   v1.21.9
aks-nodepool1-11120100-vmss000002   Ready    agent   26h   v1.21.9

$ kubectl get namespaces
NAME              STATUS   AGE
default           Active   26h
kube-node-lease   Active   26h
kube-public       Active   26h
kube-system       Active   26h
trident           Active   23h

$ cat ingressclass.yaml
apiVersion: v1
items:
- apiVersion: networking.k8s.io/v1
  kind: IngressClass
  metadata:
    annotations:
      meta.helm.sh/release-name: cloudbees-core
      meta.helm.sh/release-namespace: cloudbees-core
    generation: 1
    labels:
      app.kubernetes.io/component: controller
      app.kubernetes.io/instance: cloudbees-core
      app.kubernetes.io/managed-by: Helm
      app.kubernetes.io/name: ingress-nginx
      app.kubernetes.io/version: 1.1.0
      helm.sh/chart: ingress-nginx-4.0.13
    name: nginx
  spec:
    controller: k8s.io/ingress-nginx
kind: List
metadata:
  resourceVersion: ""
  selfLink: ""

$ kubectl create -f ingressclass.yaml
ingressclass.networking.k8s.io/nginx created

$ kubectl get ingressclass
NAME    CONTROLLER             PARAMETERS   AGE
nginx   k8s.io/ingress-nginx   <none>       60s

Now, let's destroy the cloudbees-main cluster to simulate our disaster!

blog33
After a couple of minutes, in the ACS console, in the cluster section, we can see how the cluster cloudbees-main is now unavailable, and there are critical notifications about it:

blog34

blog35

Now, to recover our CloudBees CI application in the cloudbees-core namespace, we have to return to the "Managed Applications" section, where the application state is "Unavailable", and in the Actions panel, select Restore:

blog36
We note that the pipelines in the my-cloudbees.com are no longer reachable:

blog37
In the wizard to guide the Restore operation, we select the "Destination cluster" as cloudbees-dr, specify cloudbees-core as the "Destination namespace" as in the original cluster and select from which backup we want to restore:

blog38
In the last step, we can see the summary of the Restore operation, with original and destination cluster and ALL the resources that will be restored in the destination namespace:

blog39
Monitoring the Restore in the cloudbees-dr AKS cluster we can see how PVCs have been created (using the same StorageClass available in destination, if the same storage class is not available, the default StorageClass is used). And there are Restore Jobs (r-xxx) restoring from the object storage bucket where the backup is stored to the PVCs:

$ kubectl get namespaces
NAME              STATUS   AGE
cloudbees-core    Active   12m
default           Active   28h
kube-node-lease   Active   28h
kube-public       Active   28h
kube-system       Active   28h
trident           Active   25h

$ kubectl -n cloudbees-core get pvc,all,ing
NAME                                                 STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS              AGE
persistentvolumeclaim/jenkins-home-cjoc-0            Bound    pvc-5a35f848-04a1-46ac-a606-36a82823487d   100Gi      RWO            netapp-anf-perf-premium   12m
persistentvolumeclaim/jenkins-home-my-cool-cicd1-0   Bound    pvc-a44dd9a3-4ac3-4805-9906-5dedc1728c2c   150Gi      RWO            netapp-anf-perf-premium   12m
persistentvolumeclaim/jenkins-home-my-cool-cicd2-0   Bound    pvc-aead74aa-9c35-4a27-9c18-8944236bd793   100Gi      RWO            netapp-anf-perf-premium   12m
persistentvolumeclaim/jenkins-home-my-cool-cicd3-0   Bound    pvc-3dab7d86-8d1d-4695-aa35-1cd45c284d60   125Gi      RWO            netapp-anf-perf-premium   12m
persistentvolumeclaim/jenkins-home-my-cool-cicd4-0   Bound    pvc-49aa2aac-2d05-4f24-9fe5-fa3f31857775   175Gi      RWO            netapp-anf-perf-premium   12m

NAME                                       READY   STATUS      RESTARTS   AGE
pod/r-jenkins-home-cjoc-0-jqdrc            0/1     Completed   0          12m
pod/r-jenkins-home-my-cool-cicd1-0-blb6g   1/1     Running     0          12m
pod/r-jenkins-home-my-cool-cicd2-0-sn587   0/1     Completed   0          12m
pod/r-jenkins-home-my-cool-cicd3-0-wp694   0/1     Completed   0          12m
pod/r-jenkins-home-my-cool-cicd4-0-kfvl7   0/1     Completed   0          12m

NAME                                       COMPLETIONS   DURATION   AGE
job.batch/r-jenkins-home-cjoc-0            1/1           5m7s       12m
job.batch/r-jenkins-home-my-cool-cicd1-0   0/1           12m        12m
job.batch/r-jenkins-home-my-cool-cicd2-0   1/1           5m50s      12m
job.batch/r-jenkins-home-my-cool-cicd3-0   1/1           4m38s      12m
job.batch/r-jenkins-home-my-cool-cicd4-0   1/1           4m34s      12m

When the restore jobs finish, ACS creates all resources in the namespace cloudbees-core of the AKS cluster cloudbees-dr:

$ kubectl -n cloudbees-core get pvc,all,ing
NAME                                                 STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS              AGE
persistentvolumeclaim/jenkins-home-cjoc-0            Bound    pvc-65fe1d2a-0a14-4999-bc42-17cbe0bf68f8   100Gi      RWO            netapp-anf-perf-premium   7h22m
persistentvolumeclaim/jenkins-home-my-cool-cicd1-0   Bound    pvc-56d7c09f-f0a3-4f11-9bcc-e72cbdf56282   150Gi      RWO            netapp-anf-perf-premium   7h22m
persistentvolumeclaim/jenkins-home-my-cool-cicd2-0   Bound    pvc-5dd08471-c8d3-418c-a53a-a3bedd5de074   100Gi      RWO            netapp-anf-perf-premium   7h22m
persistentvolumeclaim/jenkins-home-my-cool-cicd3-0   Bound    pvc-03267e3f-f112-4373-ada9-f01c6317394e   125Gi      RWO            netapp-anf-perf-premium   7h22m
persistentvolumeclaim/jenkins-home-my-cool-cicd4-0   Bound    pvc-2cfaa826-65d9-46b6-b686-b18e6ebd7e42   175Gi      RWO            netapp-anf-perf-premium   7h22m

NAME                                                          READY   STATUS    RESTARTS   AGE
pod/cjoc-0                                                    1/1     Running   0          6h40m
pod/cloudbees-core-ingress-nginx-controller-684dfdf69-dwp48   1/1     Running   0          6h40m
pod/my-cool-cicd1-0                                           1/1     Running   0          6h43m
pod/my-cool-cicd2-0                                           1/1     Running   0          6h42m
pod/my-cool-cicd3-0                                           1/1     Running   0          6h43m
pod/my-cool-cicd4-0                                           1/1     Running   0          6h40m

NAME                                                        TYPE           CLUSTER-IP     EXTERNAL-IP     PORT(S)                      AGE
service/cjoc                                                ClusterIP      10.0.132.172   <none>          80/TCP,50000/TCP             6h43m
service/cloudbees-core-ingress-nginx-controller             LoadBalancer   10.0.98.27     20.228.87.215   80:30049/TCP,443:32544/TCP   6h42m
service/cloudbees-core-ingress-nginx-controller-admission   ClusterIP      10.0.124.195   <none>          443/TCP                      6h43m
service/my-cool-cicd1                                       ClusterIP      10.0.208.211   <none>          80/TCP,50001/TCP             6h42m
service/my-cool-cicd2                                       ClusterIP      10.0.206.83    <none>          80/TCP,50002/TCP             6h40m
service/my-cool-cicd3                                       ClusterIP      10.0.119.29    <none>          80/TCP,50003/TCP             6h43m
service/my-cool-cicd4                                       ClusterIP      10.0.211.240   <none>          80/TCP,50004/TCP             6h42m

NAME                                                      READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/cloudbees-core-ingress-nginx-controller   1/1     1            1           6h40m

NAME                                                                DESIRED   CURRENT   READY   AGE
replicaset.apps/cloudbees-core-ingress-nginx-controller-684dfdf69   1         1         1       6h40m

NAME                             READY   AGE
statefulset.apps/cjoc            1/1     6h40m
statefulset.apps/my-cool-cicd1   1/1     6h43m
statefulset.apps/my-cool-cicd2   1/1     6h42m
statefulset.apps/my-cool-cicd3   1/1     6h43m
statefulset.apps/my-cool-cicd4   1/1     6h40m

NAME                                      CLASS   HOSTS   ADDRESS         PORTS   AGE
ingress.networking.k8s.io/cjoc            nginx   *       20.228.87.215   80      6h40m
ingress.networking.k8s.io/my-cool-cicd1   nginx   *       20.228.87.215   80      6h40m
ingress.networking.k8s.io/my-cool-cicd2   nginx   *       20.228.87.215   80      6h39m
ingress.networking.k8s.io/my-cool-cicd3   nginx   *       20.228.87.215   80      6h39m
ingress.networking.k8s.io/my-cool-cicd4   nginx   *       20.228.87.215   80      6h39m

As we can see, all Kubernetes resources have been restored. In the ACS console, within the "Managed Applications" tab, a new managed namespace cloudbees-core has appeared in the cloudbees-dr AKS cluster.

blog40
All restored or cloned applications are automatically managed by ACS. In this way, we can start protecting it with snapshots and backups, so that at some point we can do a "Failback" to recover an AKS cluster back to our preferred production region.

As in the restored namespace in the cloudbees-dr cluster, the Load Balancer has been created with a different public IP address, as the last step of our Disaster Recovery, we should update in our corporate DNS the entry for my-cloudbees.com to point to this new IP address. In our case, we'll do that in the local /etc/hosts:

$ sudo vi /etc/hosts
Password:

$ cat /etc/hosts
##
# Host Database
#
# localhost is used to configure the loopback interface
# when the system is booting.  Do not change this entry.
##
127.0.0.1    localhost
255.255.255.255     broadcasthost
::1             localhost
#20.126.199.140     my-cloudbees.com
20.228.87.215       my-cloudbees.com

Now, we should be able to reach our CloudBees CI controllers, and check the status of our controllers and pipelines:

blog41

All the controllers are up and healthy:

blog42

Our my-cool-cicd1 controller still has 2 builds executed for the make-pv-fat pipeline:

blog43
And now, we can run another build, the #3 of make-pv-fat, just to check that Jenkins is completely operational:

blog44

All our developers can resume their work after successful Disaster Recovery of all Jenkins controllers and the entire CloudBees CI platform.

Summary

In this article we described how we can make CloudBees CI, for massively managed Jenkins instances running on AKS using Azure NetApp Files, resilient to disasters, enabling us to provide business continuity for the platform. NetApp® Astra™ Control makes it easy to protect business-critical AKS workloads (stateful and stateless) with just a few clicks. Get started with Astra Control Service today with a free plan.

Luis Rico, Business Development Manager, Astra

Business Development Manager, Astra
